Hugong Econopipe-F 3 axis CNC Pipe Cutting Plasma Machine
Hugong Econopipe-F 3 axis CNC Pipe Cutting Plasma Machine
- A professional and economic pipe cutter
- Easy installation
- Strong steel structure
- Friendly interface, easy operation
- Supply with easy and economic software
- Flame and Plasma options
- Portable machine, good for contract-based production
- FreePIPE functions
- Input existing drawings
- Modify drawings easily
- Optimize drawing details
- Generate G-codes
More Information
| Model | ECONOPIPE |
| Cutting process | Plasma, no flame |
| Input voltage(V,Hz) | 110V/220V 50/60HZ |
| Installation space | 9000*1500*1380mm |
| Power consumption (not plasma) | 5KW |
| Plasma power consumption | Depends on plasma unit |
| Pipe diameter (mm) | 60-260mm |
| Pipe length (mm) | 6000mm |
| Square size | 50-180mm |
| Square tube length | 6000mm |
| Track length | 6500mm |
| Idle speed (mm/min) | 6000mm/min |
| Chuck and lock | Automatic |
| Positioning accuracy | 0.5mm/6000mm |
| Repeating accuracy | 0.2mm/6000mm |
| Axis | 3 axis, no bevelling |
| CNC | HG822-F, 17'' monitor |
| Software for design and nesting | HG822 NESTING |
| Drawing format | .dxf |
| Motors | Panasonic, 7 sets |
| Torch height sensor | Automatic |
| Construction | 2 sections for 6000mm |
| Maximum loading (kgs) | 500kg |
| Maximum pipe to load | Dia 260mm*6000*10mm |
| Dross free cutting thickness | 10mm |
| Maximum wall thickness | 10mm |
| Gross weight | 1270kg |
| Net weight | 1120kg |
| Package size | 4000*1600*1700mm |
| Loading condition | 2 sets/20‘GP |
FREEPIPE SOFTWARE
